HARDWARE FEATURES Interface 4 10/100Mbps LAN ports
1 10/100Mbps WAN portButton WPS/Wi-Fi Button
Reset Button
Power On/Off ButtonExternal Power Supply 9V/0.6A(EU), 9V/0.85A(US) Dimensions ( W x D x H ) 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm) Antenna 2 × 2.4GHz Antennas
1 × 5GHz AntennaWIRELESS FEATURES Wireless Standards IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHzFrequency 2.4GHz and 5GHz Signal Rate 5GHz: Up to 433Mbps
2.4GHz: Up to 300MbpsReception Sensitivity 5GHz:
11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm;
11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9:
-62dBm
2.4GHz:
11g 54M: -76dBm11n; HT20 MCS7: -73dBm;
11n HT40 MCS7: -71dBmWireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption Transmission Power CE:
<20dBm(2.4GHz)
<23dBm(5GHz)SOFTWARE FEATURES Quality of Service WMM, Bandwidth Control Management Access Control
Local Management
Remote ManagementPort Forwarding Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS DynDns, Comexe, NO-IP VPN Pass-Through PPTP, L2TP, IPSec Access Control Parental Control, Local Management
Control, Host List,
Access Schedule, Rule ManagementFirewall Security DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding Protocols Supports IPv4 and IPv6 Guest Network 2.4GHz guest network × 1
5GHz guest network × 1OTHERS Certification CE, RoHS Package Contents AC750 Wireless Dual Band Router Archer C20
Power Adapter
RJ45 Ethernet Cable
Quick Installation GuideBox Dimensions (W X D X H) 14 x 8.8 x 2.7 in. (357x223x68mm) System Requirements Microsoft Windows XP/Vista/7/8/8.1/10, MAC OS, UNIX or Linux
Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browsers
Cable or DSL or Fiber Modem/Terminal
Subscription with an Internet Service Provider (for Internet access)Environment Operating Temperature: 0????~40 ???? (32 ????~104????)
Storage Temperature: -40????~70 ???? (-40 ????~158????)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Description
xTpLink Router AC750 Archer C20 Wireless Dual Band Router
Brand TPLINK
Category Wireless Router
Model number TPLINK AC750 Wireless Dual Band Router Archer C20
- Supports 802.11ac standard - the next generation of Wi-Fi
- Simultaneous 2.4GHz 300Mbps and 5GHz 433Mbps connections for 733Mbps of total available bandwidth
- 3 external antennas provide stable omnidirectional signal and superior wireless coverage
